10N.m-500N.m Auto Torsion Spring Tester

Product description:

10N.m-500N.m Auto Torsion Spring Tester

Share With:

We're here to help:
Easy ways to get the answers you need.
Send E-mail Chat Now


Product Description

This machine is mainly used for torsion test of various torsion springs, scroll springs,Flat Spiral Spring and other elastic torsion parts. Measure the torque of the spring at a certain rotation angle, or measure the rotation angle of the spring at a certain torque.

Technical Parameters



Model

NDS-100

NDW-100

NDS-200

NDW-200

NDS-300

NDW-300

NDS-500

NDW-500

Type

Horizontal

Max test torque

200Nm

Test range

1%-100%FS

Min torque reading

0.1Nm

Resolution of torsion angle

0.1°

Test rotation angle

0~±360°

Accuracy of testing force

±1%

Relative error of torque zero

±0.1%

Maximum height of the sample

120mm

Distance between the force plate and the torque plate

0~200mm

Diameter of torsional plate

120mm

10N.m-500N.m Auto Torsion Spring Tester
