1000N.m-5000N.m Digital auto Torsion Spring Tester

Product description:

1000N.m-5000N.m Digital auto Torsion Spring Tester

Share With:

We're here to help:
Easy ways to get the answers you need.
Send E-mail Chat Now


Main Application :

TNS series vertical manual torsion spring testing machine applies to twist spring, spring, elastic elements of rotor rolls and friction of the torsional horn, the test of torsional moment. It is the ideal testing equipment of industrial and mining enterprises, the technical supervision, inspection arbitration, scientific research institutes, universities and quality inspection unit and other departments.

Main Specs :

Model

TNS-50

TNS-100

TNS-200

TNS-500

TNS-1000

TNS-2000

TNS-5000

Max Test force

50 N/mm

100 N/mm

200 N/mm

500 N/mm

1000 N/mm

2000 N/mm

5000 N/mm

Test range

2%-100%

Test machine class

1 class

Test force Min reading value

0.1 Nmm

Angle min reading value

0.1°

Torque indicate relative error

≤ ±1%

Spring test length

0-70mm

Deformation error

≤±50+0.15l

Test angle range

0-±9999.9

Torque dish diam

100mm

180mm

Loading method

Manual Loading

Power supply

AC 220V/50Hz
