HST-PNZ electro-hydraulic servo torsional fatigue test machine
Application:
HST-FN electro-hydraulic servo torsional fatigue test bench is suitable for torsional fatigue testing of products such as cardan shaft and constant shafts. As required, relevant fatigue life tests may be carried out on other types of structural members and assemblies according to relevant standards.
| No. | Item | Main specifications and technical indicators: |
| 1 | Max.test torque | ±5000N.m,indication accuracy2%FS ±1% |
| 2 | Max.angle of rotation | ±50º |
| 3 | Corner indication accuracy | ±0.5%FS |
| 4 | Servo valve | 100L/min,21MPa,double valve parallel structure |
| 5 | Sample length | 300-1500mm |
| 6 | The height of the loading point center | not less than 220mm |
