HST-PT20 Rubber plate Vulcanizing Press Testing Machine
HST-PT20 Rubber plate Vulcanizing Press Testing Test Machine
Standards:
Request A Quote Files DownloadIntroduction:
This series Rubber plate Vulcanizing Press Testing Test Machine is the main equipment used to press and mold various rubber model products and non-mold products. They can also be used to press various thermosetting plastics and foamed rubber and plastic products. It has independent power mechanism and electrical system, and uses button centralized control. The working pressure and heating temperature can be adjusted within a certain range. This machine is divided into two types: manual and semi-automatic.
Specification:
|
Capacity |
20 ton /30Ton |
|
Pressure setting |
The pressure can be set in the touch screen, which can be controlled by 15 segments, pressure, temperature, time |
|
Accuracy |
±400kg |
|
Pressure plate (mm) |
300*300 |
|
Hot press plate material |
Imported high-temperature-resistant steel plate, surface carbonization and quenching, special treatment for fast heat conduction, parallel pressure unchanged, wear-resistant. |
|
Platen hardness |
50〜60HRC |
|
Platen flatness |
<0. 03mm |
|
Platen parallelism |
<0.16mm |
|
Temperature range |
Room temperature-300°C |
|
temperature uniformity |
±1.5°C |
|
Temperature Controller |
PLC touch screen control |
|
Temperature control accuracy |
±1.0°C |
|
Timer |
Touch screen setting, time range is 0.1 S~99min~9.9hr |
|
Heater |
Heating mold built-in cylindrical type |
|
Heating time |
It takes about 15 minutes at room temperature to 160 °C |
|
Heating method |
Electric heating |
|
Cooling method |
Natural cooling |
|
Cylinder stroke |
Max 150mm |
|
Cylinder speed |
11mm/s |
|
Pressure gauge |
0 〜200kg/sq.cm |
|
Safety equipment |
Safety door, safety cover |
|
Safety equipment qty. |
4pcs |
|
Dimension(W×D×H) |
1100*650*1500 mm |
|
Power supply |
3 phase,AC380V |
|
Weight |
About 700kg |
