HST-RMD300 Rubber No Rotor Rheometer
1.Applicable Industry:
It is suitable for testing the variation of shear modulus when raw rubber is vulcanized. The shear modulus is proportional to the crosslinking density. So the results reflect the changes in the degree of crosslinking during vulcanization. So that we can measure the parameters like curing speed, Curing time and desulfurization.2.Meet standard:
GB/T16584— use rotorless curemeter to test vulcanization characteristics
ISO6502 Vulcanizing machine standard data
ASTMD5289 Rubber properties test methods
3.Technical Parameters:
|
MODEL |
HST-RMD300 |
|
Temperature range |
RT~200℃ |
|
Minimum temperature display |
0.1℃ |
|
Temperature fluctuation range |
±0.15℃ |
|
Heating rate |
About 15℃/min |
|
Torque range |
0-20mm |
|
Torque minimum reading |
0.001nm |
|
Swing angle |
±0.5°/ ±1°/ ±3°(optional) |
|
Swing speed |
100r/min(1.66HZ) |
|
Torque accuracy |
0.3% |
|
Temperature display resolution |
0.01℃ |
|
Temperature recovery time |
< 1.5min |
|
Temperature unit |
C (degrees Celsius), F (Fahrenheit), K (Kelvin) |
|
Acquisition rate |
200time/s |
|
Software language |
English, Chinese Simplified, Chinese Traditional |
|
Software connection |
USB2.0 |
|
Power |
1 phase 220V±15V 50HZ |
|
Dimensions |
600×600×1180㎜ |
|
Weight |
230㎏ |
