Model | HYJ-600S | HYJS-1000S |
Max test force (kn) | 600 | 1000 |
Effective test space(mm) | 1200×1200 | |
Table height(mm) | 200 | |
Force accuracy | ±1% | |
Max. piston moves speed | 80 mm/min | |
Maximum compression space | 400 mm | |
Compression plate size |
Φ 360 (GB Standard) or 250 (Europe standard) | |
Deformation measuring range (mm) | 0-20 | |
Piston stroke |
350 mm | |
Power supply | 380V/220V 1.5kw | |
Mainframe dimensions (length × width × height) (mm) | 2400×1200×1400 |
