Application to the tensile and creep relaxation strength test if the round specimen, rectangular specimen, and tubular product and other products under GB/T4338 (metal material of high temperature tensile test method),HB5195 (The metal high temperature tensile test method) , GB/T2039( the tensile creep rupture and test method), HB5150(metal high temperature tensile durable test method)
Main technical parameter about the high temperature part:
Model
WDW-10GD
WDW-20GD
WDW-30GD
WDW-50GD
WDW-100GD
Max. Load(kN)
10
20
30
50
100
Load accuracy
Class 0.5
Load range
0.2%~100%F·S
Load resolution
1/500000
Resolution of deformation
0.04um
Accuracy of displacement
Within±0.5%of indicating load
Resolution of displacement
0.01mm
Test speed(mm/min)
0.05-1000 stepless arbitrary setting
Speed accuracy
within ±1% / ±0.5% of set speed
E-Tensile space(mm)
670
670
770
770
650
E-Compression space(mm)
900
900
900
1000
1000
D-Test width(mm)
450
450
450
450
550
F-Beam travel distance(mm)
1000
1000
1100
1100
1100
Power supply
AC220V±10%,50Hz/60Hz (can be customized)
