Model | YAW-2000BG |
Max. Load | 2000kN |
Control method | Computer auto control loading process |
Oil source control cabinet structure | One-piece oil source control cabinet |
Test class | 1 class |
Testing range | 4%-100%FS |
Load display accuracy | Better than ±1% |
Piston stroke | 120mm |
Distance between upper and lower platen | 360mm |
Size of upper and lower platen | Φ300mm |
Power supply | 2.0Kw/AC380V |
