WDW-EGD 200KN 300KN 20T30T High and Low Temperature Tensile Test Machine
High and Low Temperature Tensile Testeris widely used in controlling the quality; Rubber & Plastics; metallurgical iron and steel; electronic equipment; other industries tensile test.
Standards:
ISO,ASTM
Request A Quote Files DownloadWDW-EGD 200KN 300KN 20T30T high and low temperature tensile test Machine
Application
High and low temperature tensile testeris widely used in controlling the quality; Rubber & Plastics; metallurgical iron and steel; manufacturing machinery; electronic equipment; automobile production; textile fiber; wire and cable; packaging materials and foodstuffs; instrumentation; medical equipment; civilian nuclear energy; civil aviation; colleges and universities; research Laboratory; inspection arbitration, technical supervision departments; building materials, ceramic; Petroleum &Chemical; other industries tensile test.Testing machine specifications
|
Model |
HST WDW-200EGD |
HST WDW-300EGD |
|
Max. Load(kN) |
200 |
300 |
|
Load accuracy |
Class 0.5 |
|
|
Load range |
0.2%～100%F·S |
|
|
Load resolution |
1/500000 |
|
|
Resolution of deformation |
0.04um |
|
|
Accuracy of displacement |
Within±0.5%of indicating load |
|
|
Resolution of displacement |
0.01mm |
|
|
Test speed(mm/min) |
0.01-500 |
0.01-500 |
|
Speed accuracy |
±0.5% of set speed |
|
|
E-Tensile space(mm) |
700 |
700 |
|
E-Compression space(mm) |
1100 |
11000 |
|
D-Test width(mm) |
600 |
600 |
|
Temperature range(℃) |
−60℃/−70℃~300℃ |
−190℃~300℃ |
|
Power supply |
AC220V±10%，50Hz/60Hz (can be customized) |
|
