HST-EDG10,20,50,100,200,300 High Temperature Tensile Testing Machine(-60-300℃）
It is widely used in controlling the quality; Rubber & Plastics tensile tester; metallurgical iron and steel; manufacturing machinery; electronic equipment; other industries.
Standards:
ISO,ASTM
Request A Quote Files DownloadHST-EDG10,20,50,100,200,300 High Temperature Tensile Testing Machine(-60-300℃）
Application
It is widely used in controlling the quality; Rubber & Plastics tensile tester; metallurgical iron and steel; manufacturing machinery; electronic equipment; automobile production; textile fiber; wire and cable; packaging materials and foodstuffs; instrumentation; medical equipment; civilian nuclear energy; civil aviation; colleges and universities; research Laboratory; inspection arbitration, technical supervision departments; building materials, ceramic; Petroleum &Chemical; other industries.Specification
| Model | HST-EDG10,20,50 | HST-EDG100 | HST-EDG200,300 |
| Max.Load(kN) | 10,20,50 | 100 | 200,300 |
| Controlmethod | Computercontrol | ||
| Loadaccuracy | Class0.5 | ||
| Loadrange | 0.2%～100%F·S | ||
| Resolutionofdisplacement(mm) | 0.01 | ||
| Testspeed(mm/min) | 0.001-1000 | 0.001-500 | 0.001-500 |
| Tensilespace(mm) | 800 | 700 | 550 |
| Compressionspace(mm) | 800 | 700 | 550 |
| Testwidth | 400 | 550 | 600 |
| Temperatureranage | -60℃~300℃ | ||
| Powersupply | AC220V±10%,50Hz/60Hz(canbecustomized) | ||
| Grips | accordingtocustomer'srequirement | ||
Temperature range:-60℃/-80℃~300℃
Inner chamber size:260*410*360mm or can according to customer's requirement
