Constant pressure servo pump station
It is used in electro-hydraulic servo dynamic and static universal testing machine and various electro-hydraulic servo component fatigue test systems.
Standards:
ISO,ASTM
Request A Quote Files DownloadConstant pressure servo pump station
Introduction:
BST series constant pressure servo pump station is the latest generation constant pressure servo pump station launched by our group. It is used in electro-hydraulic servo dynamic and static universal testing machine and various electro-hydraulic servo component fatigue test systems. It has the feature of low noise, smooth operation and long life.And it with temperature, liquid level, oil filter clogging alarm or stop function.Technical parameters
| Model | HST23 | HST36 | HST45 | HST70 | HST90 | HST110 | HST140 | HST175 | HST230 |
| Flow(L/min) | 23 | 36 | 45 | 70 | 90 | 110 | 140 | 175 | 230 |
| System pressure(MPa) | 21 | 21 | 21 | 21 | 21 | 21 | 21 | 21 | 21 |
| Power(Kw) | 10 | 15 | 22 | 30 | 37 | 55 | 55 | 75 | 110 |
