HST-PU-22001-A0-000 Hydraulic Oil Circuit Control Valve Group
Technical Parameters:
|
System parameters |
Specifications |
|
|
Working medium |
46# Hydraulic oil |
|
|
Environment |
Temperature |
4.4℃-60℃ |
|
Humidity |
0%-80% |
|
|
Channel |
Dual channel |
|
|
Filtration accuracy |
Main Oil Line |
10µ |
|
Pilot oil circuit |
3µ |
|
|
preset pressure |
21MPa |
|
|
Limited Data |
Main oil circuit |
380L/min |
|
Pilot oil circuit |
10L/min |
|
|
Single channel traffic |
160L/min |
|
|
Slow start boost time |
5.0-9.0 s |
|
|
Solenoid valve control parameters |
24VDC/1.5A |
|
|
Accumulator |
Main oil circuit |
3.8L |
|
Oil return line |
1.9L |
|
|
Pilot oil circuit |
0.45L |
|
|
Interface Specifications |
Pressure port |
Code1 :1 1/2" |
|
Oil return port |
CODE1:1 1/2" |
|
|
Pilot pressure port |
M14X1.5 |
|
|
Pilot return port |
M14X1.5 |
|
|
Leak port |
M14X1.5 |
|
