High and low Temperature Torsion Testing Machine

Application

This series torsion testing machine is suitable for metal materials, non-metallic materials, composite materials and components of torsion performance test.

Standard

GB/T 10128-1998 《Metal room temperature torsion test method》
GB/T 10128-2007 《Metal room temperature torsion test method》



Specification

Model	NDW- 100G	NDW- 200G	NDW- 500G	NDW- 1000G	NDW- 2000G	NDW- 3000G	NDW- 5000G
Maximum Torque (N/m)	100	200	500	1000	2000	3000	5000
Control Method	Constant torque and constant speed rotation, constant speed twist angle , close loop control mode
Machine level	1 Class
Torque Test Range(F·S)	2%-100%F·S
Torque value relative error(%)	≤±1
Torque display resolution	1/20000
Torsional Angle Test Range(F·S)	2%-100%
Torsional Angle value relative error (%)	Better than ±0.5
Torsional Angle display resolution	1/20000
intersection angle value relative error (%)	≤±1
intersection angle display resolution(°)	0.01
Max. torsion Angle	99999°
Torsional angular rate control range (°/min)	0.05-800
Chuck spacing effectively (mm)	600
Power Supply	220V±10%, 50Hz
High Temperature test chamber
Temperature range	＋20℃~200℃ or -40-200200℃
Temperature fluctuation	≤±1℃
Cooling system	compressor
