HST NSM525-E Electric Dumbbell Specimen Making Machine
This dumbbell type sample making machine is a special equipment mainly used for making standard sample strips of non-metallic materials. This equipment has the characteristics of simple operation, fast sample making, standard sample and stable size; it is suitable for pipe production enterprises, product quality supervision and inspection institutes, building science research institutes, etc. to make standard sample strips for functional and performance testing of non-metallic materials such as plastics.
2. Related standards
It’s available to make specimen for
2.1 ISO 6259-2 type 1, ISO 6259-3 type 1, ISO 6295-3 type 2 .
2.2 ISO 527-2 type 1A, ISO 527-3 type 2
2.3 HDT test
2.4 Vicat test
2.5 Other specimens, such as Aluminum, Magnesium, and alloy specimen, thickness is more than 3mm and less than 10mm.
3.Technical indicators
MODEL
HST NSM525-E
Dumbbell
Automatic
Specimen specifications
TypeⅠA,TypeⅠB,Type Ⅱ,Type P1,Type P2
Temperature control range
Ambient temperature
Motor speed (r/min)
1400
Main motor power (W)
180
Vacuum cleaner power (W)
1200
Power supply
220V±10% 5A 50Hz
Dimensions (length * width * height, mm)
Approx. 570*500×*470
Weight (kg)
Approx. 50
Specimen length(mm)
≤170
Specimen width(mm)
16~30
Specimen thickness(mm)
3~25
