Applications:

Industrial production, Inspection of product quality on processing technology. Ferrous and nonferrous metals, Hardened steel, tempered steel, annealed steel, hardened steel, sheet of various thicknesses, carbide materials, powder metallurgy materials, hardness and thermal spray coating. Sheet metal, thin-walled pipe, hardened steel, and small parts of hardness. Widely used in machinery manufacturing, metallurgy plants, universities, laboratories, etc.

Technical specifications:

Conversion Scale	Brinell, Vickers
Display of Hardness Value	Touchable Large LCD screen display
Data output	Inside Printer, RS-232
Duration time	0-60s
Carried Standard	BSEN 6508， ISO 6508， ASTM E18， GB/T230
Preliminary Testing force	3.0kgf(29.4N)
Testing force	15kgf(147.1N)   30kgf(249.2N)    45kgf(441.3N)
Hardness measuring range	HR15N：70-94 HR30N：42-86 HR45N：20-77 HR15T：67-93 HR30T：29-82 HR45T：1-72
Test force Deviation	≤0.5%
Testing accuracy	0.1
Max Height of Specimen	300mm
Distance of Indenter to outer wall	250mm
Power supply	AC220V+5%,50-60Hz
Overall Dimensions	720×260×840mm
Data Output	USB Flash Disk
