HST-HSR45T Digital Display Superficial Rockwell Hardness Tester
Can use diamond indenter and steel ball indenter, can measure hard and soft samples, widely used to determine the Rockwell hardness of ferrous metals, non-ferrous metals,non-metallic materials
Standards:
ASTM, ISO
Request A Quote Files DownloadApplication:
Rockwell Hardness Test method, can use diamond indenter and steel ball indenter, can measure hard and soft samples, widely used to determine the Rockwell hardness of ferrous metals, non-ferrous metals,non-metallic materials. It is mainly used to measure Rockwell hardness of heat treated materials such as quenching and tempering.Such as hard alloy, carburized steel, hardened steel, surface hardened steel, hard cast steel, aluminum alloy,copper alloy, malleable castings, mild steel, tempered steel, annealed steel, bearings and other Materials.
Technical Parameters:
|
Test force |
15kg, 30kg, 45kg |
|
|
Measuring scope |
70-91HR15N,42-80HR30N,20-70HR45N, |
|
|
Indenter |
Diamond indenter |
ф1.588mm Ball indenter |
|
Measuring space |
Max testing height:230mm |
|
|
Throat:170mm |
||
|
Test force loading method |
Initial test force:Manual |
|
|
Measuring scale |
HR15N,HR30N,HR45N,HR15T,HR30T,HR45T |
|
|
Convert scale |
HV,HK,HRA,HRBW,HRC,HR15N,HR30N,HR45N,HR15TW,HR30TW,HR45TW,HBW |
|
|
Hardness disply method |
8” touch screen(can connect PC showing) |
|
|
Hardness resolution |
0.1HR |
|
|
Power supply |
AC 220V 50/60 Hz |
|
