1.Application:
It's suitable to determine the Brinell hardness of unquenched steel,cast iron, non-ferrous metals and soft bearing alloys, etc.
2.Technical Parameter:
Model
|
HB-3000D
|
Measuring Range
|
8-650HBW
|
Test Force
|
612.9, 980.7, 1225.9, 1838.8, 2451.8, 7355.3, 9807, 14710.5, 29421N. (62.5, 100, 125, 187.5, 250, 750, 1000, 1500, 3000kgf)
|
Diameter Of Tungsten Carbide Ball
|
2.5mm, 5mm, 10mm
|
Dwelling Time Of Test Force
|
2-99s
|
Max. Height Of Test Piece
|
390mm
|
Depth Of Throat
|
200mm
|
Power Supply
|
220V AC or 110V AC, 50 or 60Hz
|
Dimensions
|
860x680x1250mm
|
Height Of Base
|
400mm
|
Weight
|
Approx. 400kg
|
