HST-PTG04 Paper Thickness Gauge
Introduction:
The HST-PTG04 paper and paperboard thickness gauge is a specialized instrument for measuring the thickness of paper and paperboard. Its main technical specifications and performance parameters comply with the relevant provisions of GB451.3 "Determination of Thickness of Paper and Paperboard". It is widely applicable to the thickness measurement of paper, paperboard and other sheet materials.
Test principle:
The actual thickness of an object is measured under a certain area and a certain load.
Specification
|
Name |
HST-PTG04 |
|
Measurement range |
0 ～ 4mm |
|
Scale division |
0.001mm |
|
Contact pressure |
100±10kPa |
|
Contact area |
200±5mm2 |
|
Measuring the parallelism of surfaces |
≤0.002mm |
|
Indication error |
±0.0025mm or ±0.5% |
|
Indication variability |
≤0.0025mm or ≤0.5% |
|
Net weight |
5KG |
|
Size |
160*120*250mm |
|
Standard configuration |
Main unit, digital dial indicator, instruction manual |
|
Reference Standard |
QBT 1055, GB451.3, etc. |
|
Optional Accessories |
Ring-crushing center disc + ring-crushing sampling knife + adhesive strength peeler + edge-crushing guide block + edge-crushing adhesive sampling knife + flat-crushing sampling knife |
