HST-KAT10 Klem Absorbency Tester
This instrument is designed and manufactured according to the technical parameters and requirements specified in QB/T1662 "Klem Absorbency Tester" and GB / T 461.1-2002 "Determination of Capillary Liq
Standards:
Request A Quote Files DownloadApplications:
This instrument is designed and manufactured according to the technical parameters and requirements specified in QB/T1662 "Klem Absorbency Tester" and GB / T 461.1-2002 "Determination of Capillary Liquid Absorption Height of Paper and Paperboard (Klem Method)" . The instrument is suitable for determining the capillary liquid absorption height of various unsized papers and paperboards. (It is not suitable for papers and paperboards with a capillary liquid absorption height of less than 5 mm within 10 minutes.)
Technical parameters:
|
model |
HST-KAT10 |
|
Test height |
5-200mm |
|
Sample size |
250*15mm |
|
Minimum scale value |
1mm |
|
Number of rulers |
5 |
|
Number of tests conducted simultaneously |
10 |
|
External dimensions |
400*200*450 mm |
|
Work environment
|
Indoor temperature 20±10 °C; relative humidity <85%; clean with little dust, free from strong magnetic fields and strong vibration sources. |
|
net weight |
10KG |
|
Reference Standard
|
QB/T1662 "Klem Absorbency Tester" and GB / T 461.1-2002 "Determination of Capillary Height of Paper and Paperboard (Klem Method)" |
