Product Application:

The aluminum foil pinhole detector conforms to the pinhole testing requirements of GB/T22638.2 and YBB00152002-2015 pharmaceutical aluminum foil.

Applicable Standards:

GB/T 22638.2, YBB00152002-2015 pharmaceutical aluminum foil, etc.

Technical Parameters

Selectable power settings: 15W, 30W, and 45W

High-transmittance glass backing

Observation size: 400×250mm

Transmitted light intensity: 1000Lux

Ambient light intensity: 20Lux-50Lux

Reading microscope magnification: 100X high-definition magnification; graduations: minimum 0.02mm, maximum 1.6mm

Dimensions: 800×600×300mm (L×W×H)

Weight: 25Kg
