HST-XHR150TE Digital Touch Screen Plastics Rockwell Hardness TesterHST-XHR150TE Plastic Rockwell Hardness Tester is aspecialized test non-metallic plastic, hard rubber, synthetic resin,friction materi
Standards:
Request A Quote Files DownloadHST-XHR150TE Digital Touch Screen Plastics Rockwell Hardness Tester
Application range:
HST-XHR150TE Plastic rockwell hardness tester is aspecialized test non-metallic plastic, hard rubber, synthetic resin,friction material and soft metal Hardness Tester. Simple operation,easy to master, high working efficiency.
Main Features:
1. This machine cancels the weight force and adopts electronic loading
2. Touch screen operation and display, humanized operation interface, complete instrument settings;
3. Bluetooth connection computer, through special hardness software analysis and management data;
4. Powerful data processing function, 8 kinds of plastic Rockwell Hardness Test scales are optional, suitable for hard plastics, hard rubber, aluminum, tin, copper, soft steel, synthetic resin and friction materials;
5. The operation interface is simple, the parameters are set in the humanized interface, and the host independently stores 500 sets of data, and the data is not lost when the power is off.
Technical Parameters:
|
Model |
HST-XHR150TE |
|
Test force |
Rockwell: 60kg, 100kg, 150kg |
|
Measurement range |
70-100HRE, 50-115HRL, 50-115HRM, 50-115HRR |
|
Indenter |
Φ3.175mmBall Indenter, Φ6.35mmBall Indenter, Φ12.7mmBall Indenter |
|
Loading Method |
Automatic (Loading/Dwell/Unloading) |
|
Hardness Reading |
8-inch touch screen display |
|
Hardness Resolution |
0.1HR |
|
Dwell Time |
0~60s |
|
Max. Sample Height |
230mm |
|
Throat Depth |
170mm |
|
Power Supply |
AC220V,50Hz |
|
Execute Standard |
ISO 6508,ASTM E18,JIS Z2245,GB/T 230.2 |
|
Dimension |
475 x 200 x 700 mm |
|
Weight |
80kg |
