LBG-32 Belt Surface Grinding Specimen Machine
This machine is of new generation design, made according to international standard and advanced process technique. Grinding and polishing the specimens with belt.
Standards:
ISO,ASTM
Request A Quote Files Download
LBG-32 Belt Surface Grinding Specimen Machine
Application:This machine is of new generation design, made according to international standard and advanced process technique. Grinding and polishing the specimens with belt. You can change the different belts in easy and efficient way. The machine can replace those grinding wheel machine and pre-grinder. It adopts manual abrasive paper grinding and each belt can finish operation within 1-2 minutes. It is economical to save time, effort and abrasive paper if grinding the spectroscopy specimens.
Main specifications:
| Model | LBG-32 |
| Distance between the centers of two rollers | 274mm |
| Cooling method | water cooling and dust separation plant |
| Power supply | 380V, 50Hz |
| Surface speed | 768 m / min |
| Rotating speed | 1400 rpm |
| Grinding size | 220 x 120mm |
| Sand belt | 1003 x 100mm (L x W) |
| Motor | 750W |
| Dimension |
580 x 600 x 980 mm |
