HST-P 50kn 100kn 200KN 250KN 5Ton 10Ton 20Ton 25Ton Control Electro-hydraulic Servo Fatigue Tester

1. Application

This series computer Control Electro-hydraulic Servo Fatigue Testing Machine is mainly used to detect a variety of metals, non-metallic materials and small movable member, the static mechanical properties test. It can do tensile, compression, bending, low cycle and high cycle fatigue, crack growth, fracture mechanics test under sine, triangle, square wave, trapezoidal wave, random wave, combination waveform.
This Test machine is flexible, moving beam down, locking the sample holder by button operations, the use of advanced hydraulic servo drive technology loaded, high precision and high resolution dynamic load sensor magnetostrictive displacement sensor specimens force values and displa
2. Standards
2.1 GB / T2611-2007 "Tester General technical requirements"
2.2 GB / T16826-2008《Hydraulic servo universal testing machine》
2.3 GB 3075 "Axial fatigue testing metal"
2.4 JB / T9379-2002 "Tension and compression fatigue test machine technical conditions"
2.5 GB / T228-2010 "Metallic materials at room temperature tensile test method"
3. Specifications

Model		HST-P50	HST-P100	HST-P200	HST-P250
Load Capacity(kN)	Static	50	100	200	250
	Dynamic	±40	±80	±160	±160
Measurement Accuracy	Load	±1.0% of Reading
	Displacement	±1.0% FS of Each File
	Deformation	±1.0% of Reading
Range Of Frequency		0.1～15Hz / 20Hz / 50Hz
Stroke of Piston(mm)		±50	±50	±75	±75
Distance Between Columns(mm)		500	500	700	700
Distance Between Grips(mm)		50~600
Specification of constant voltage servo pump station		flow≥37L/min, 21Mpa, 380V three phase
