NDT Series Drop Weight Impact Testing Machine(2000J~6000J)

NDT Series Drop Weight Impact Testing Machine(2000J~6000J)
NDT Series Drop Weight Impact Testing Machine(2000J~6000J)
NDT Series Drop Weight Impact Testing Machine(2000J~6000J)

Functions

This type of machine is specially for conducting drop-weight test to determine nil-ductility transition (NDT) temperature of ferritic steels

Standards: GB/T 6803, ASTM E208

Main Technical Parameters:
Model NDT-2000 NDT-3000 NDT-4000 NDT-6000
Maximum Energy(J) 2000 3000 4000 6000
Minimum Energy(J) 300 300 500 750
Maximum Tup Mass(kg) 60 90 120 204
Tup Mass Accuracy ±1%
Drop Height(mm) 750~3400 750~3000
Velocity Of Drop(m/s) 3.8~7.6
Hammer Lifting Speed(m/min) 3
Height Resolution 0.1
Height Accuracy(mm) ≤±10
Hardness Of Tup Nose HRC58-62
Radius Of Tup Nose(mm) R25.4±2.5
Sample Centered Error(mm) ±1
Support Anvil Span P-1、P-2、P-3
Specimen Dimension P-1:(360±1)×(90±2)×(25±2.5)P-2:(130±1)×(50±1)×(20±1)P-3:(130±1)×(50±1)×(16±0.5)
Power Supply 380v±10%,50/60Hz
