HNR-400CD Touch Screen Melt Flow Indexer（MFR & MVR ）
Instrument overview
This machine is not only suitable for engineering plastics such as polyethylene, polyarylsulfone, fluoroplastics, nylon, etc., with higher melting temperature, but also suitable for plastics with lower melting temperature such as polyethylene, polystyrene, polypropylene, ABS resin, and polyoxymethylene resin. test. Especially suitable for universities, research institutes, quality inspection institutions, plastic manufacturers, plastic products and petrochemical industries.
Environmental requirements:
1) Ambient temperature: within the range of 10℃-40℃;
2) The relative humidity of the environment is within 30%-80%;
Technical Parameters
Measuring range: (0.2～100)g/10min
|
Melt Flow Indexer |
|
|
Temperature control range |
120℃～450℃，fast heating speed, extremely small overshoot |
|
Temperature display error |
≤±0.2℃, high precision of constant temperature |
|
Temperature display resolution |
0.1℃ |
|
Recovery Time |
≤4min, can quickly restore the constant temperature state after filling |
|
Display method |
Color touch screen display and operation |
|
Measurement methods |
Quality method |
|
Timing accuracy |
0.1 second |
|
Cutting method |
Manual and automatic cutting methods |
|
Cutting time interval |
1—36000S |
|
Die material |
Tungsten carbide |
|
Die diameter |
2.095±0.005 mm |
|
Instrument size |
Length 260mm × width 400mm × height 600mm |
|
Required space |
0.4m front and rear, 0.4m left and right |
