HGW Series Pipe Ring Stiffness Testing Machine
1.Application: It is widely used in thermoplastic plastic tubing with circular cross section, and the stiffness for grass steel tube. The tester can meet the standard requirement of PE arms bellows,wi
Standards:
Request A Quote Files Download
1.Application:
It is widely used in thermoplastic plastic tubing with circular cross section, and the stiffness for grass steel tube. The tester can meet the standard requirement of PE arms bellows,winding pipe, and all kinds of tubular product standards, at the same time, can do the tubular product ring stiffness,ring flexibility,flat,tensile test.
2.Standards:
GB/T 18042, ISO 9967and other standards
3.Specifications:
It is widely used in thermoplastic plastic tubing with circular cross section, and the stiffness for grass steel tube. The tester can meet the standard requirement of PE arms bellows,winding pipe, and all kinds of tubular product standards, at the same time, can do the tubular product ring stiffness,ring flexibility,flat,tensile test.
2.Standards:
GB/T 18042, ISO 9967and other standards
3.Specifications:
| Model | HGW-50E | HGW-100E | HGW-200E | HGW-300E | HGW-500E | HGW-600E | ||||||
| Calibration Standard | Class 0.5 | |||||||||||
| Load Range | 0.2%~100%F·S | |||||||||||
| Displacement Resolution | 0.001mm | |||||||||||
| Resolution of Displacement | 1/300000 | |||||||||||
| Column | 4 Column,2Screw | |||||||||||
| Test Speed(mm/min) | 0.01~1000 | 0.01~500 | 0.01~500 | |||||||||
| Crosshead Speed | ±0.5% of set speed | |||||||||||
| Crosshead travel(mm) | 1000 | 1100mm | 800 | |||||||||
| EffectiveTestingDiameterofPipe |
According to Customer’sRequirementsCustomize(0-3000mm) |
|||||||||||
| EffectiveTest Width(mm) |
According to Customer’sRequirementsCustomize,≥Pipe Diameter20% |
|||||||||||
| Power Supply |
AC 220V50Hz / 60Hz |
|||||||||||
