HBM-3000E Automatic Gantry Brinell Hardness Tester
Application:
This machine is an important instrument for testing the hardness of various castings, annealed steel,
normalized steel and other metal cloth. It adopts high-precision load cell and high-resolution displacement
sensor to ensure accurate measurement; it has the characteristics of stable loading, low vibration, low noise,
and high precision.
Specification：
(1) Measurement parameters
Maximum test force (kg):750、1000、3000kgf
Hardness tester level: 0.5;
Test force measurement range (kg): 32-450HBS，32-650HBW;
Test force measurement accuracy: better than ≤±0.5%;
Displacement measurement resolution (mm): 0.01;
Displacement measurement accuracy: better than ≤±0.5%;
Displacement control speed range: 0.01～500mm/min;
(2) Host parameters:
Number of columns: 6 columns (4 columns, 2 screws);
Effective span (mm): 550（customized）
Max height of test piece: 1200mm（customized）
